PSRSP
Information
Anaheim Automation’s PSRSP series offers versatility and functionality. Integrated into the power supply is a PFC function, ranging from PF>0.93 to PF>0.95, as well as a built-in constant current limiting circuit, so the unit draws less current and provides up to 90% efficiency. Each power supply is equipped with an LED indicator for power on in addition to short-circuit, overload, over voltage, and over temperature protection features. In addition to flexibility and cost-efficiency, the PSRSP series offers high reliability and a long lifetime.
- Universal AC Input/Full Range
- Built-In Active PFC Function
- High Efficiency Up to 90%
- Fixed Switching Frequency
- CE Certified
| Item (click for more information) | Input Voltage (VAC) | Output Voltage (V) | Total Power (W) | Lead Time | 1pc Price (USD) | Add to Cart |
|---|---|---|---|---|---|---|
| PSRSP-320-48V-6.7A | 88-264VAC, Single Phase, 47-63Hz | 48 | 320 | Typ 20 Days | $109.00 | Call Us Contact Us |
| PSRSP-320-36V-8.9A | 88-264VAC, Single Phase, 47-63Hz | 36 | 320 | Typ 20 Days | $109.00 | Call Us Contact Us |
| PSRSP-320-24V-13.4A | 88-264VAC, Single Phase, 47-63Hz | 24 | 320 | Typ 20 Days | $109.00 | Call Us Contact Us |
| PSRSP-200-48V-4.2A | 88-264VAC, Single Phase, 47-63Hz | 48 | 200 | Typ 20 Days | $91.00 | Call Us Contact Us |
| PSRSP-200-24V-8.4A | 88-264VAC, Single Phase, 47-63Hz | 24 | 200 | Typ 20 Days | $91.00 | Call Us Contact Us |
| PSRSP-150-48V-3.2A | 85-264VAC, Single Phase, 47-63Hz | 48 | 150 | Typ 20 Days | $79.00 | Call Us Contact Us |
| PSRSP-150-24V-6.3A | 85-264VAC, Single Phase, 47-63Hz | 24 | 150 | Typ 20 Days | $79.00 | Call Us Contact Us |
Additional Information
