MDCKB1-120081-OL
MDCKB1-120081-OL | Anaheim Automation, Inc.
Information
.png)
The MDCKB1-120081-OL is a Brushless DC Driver with a varying velocity mode. This driver eliminates the need for an external power supply with a motor bus voltage of 160VDC and a maximum phase current of 8A (peak). The driver is protected against over-current (cycle-by-cycle), hall sensor error and under-voltage. A fault LED light illuminates to notify the user when an error occurs. This driver utilizes an internal potentiometer to control the maximum phase current allowed into the motor and an external potentiometer to control the speed of the motor.
- 85-135VAC Input
- 160VDC Motor Bus
- 400W, 8A Peak
- Varying velocity mode
- No external power supply required
- Open Feedback Loop
| Item | Input Range | Max Power (W) | Peak Current (A) | Feedback Loop | Lead Time | 1pc Price (USD) | Add to Cart |
|---|---|---|---|---|---|---|---|
| MDCKB1-120081-OL | 85 - 135VAC | 400 | 8 | Open | Typ 35 Days | $127.00 |
Additional Information
.png)
