main product photo
Loading...
BDPG-22-31-12V-6000-R1966

BDPG-22-31-12V-6000-R1966

BDPG-22-31-24V-6000-R53

BDPG-22-31-24V-6000-R53

BDPG-22-31-24V-6000-R4

1pc Price:
$71.00
Quantity Discount
  • Buy 10 for $63.60 each and save 10%
  • Buy 25 for $63.35 each and save 11%
  • Buy 50 for $34.41 each and save 52%
  • Buy 100 for $29.35 each and save 59%
Inventory:
More Information
Gear Ratio 4
Rated Torque (oz-in) 1.67
Peak Torque (oz-in) 10
No Load Speed (rpm) 1500
Rated Speed (RPM) 1000
Nominal Voltage (V) 24
Rated Current (A) 0.145
Output Power (W) 1.79
Body Diameter (mm) 22
Total Length (mm) 44.4
Gearbox Length "L" (mm) 14.4
Shaft Diameter (mm) 4
Weight (lbs) 0.15
Interested in large quantity discount?
Be the first to review this product

Product Information

The BDPG 22 Series was designed for high volume OEM applications with low cost being the primary objective. These reliable low cost Brush DC Planetary Gearmotors come in a variety of power levels and sizes that will be sure to fit your needs. The motors are fully reversible. The BDPG 22 Series is a cost-effective solution to manage motion control in many rotary applications including medical, semiconductor, pumps, robotics, hobby, CNC, and many other applications where a low cost Brush DC Planetary Gearmotor is needed.

  • DC Brush Planetary Gearmotor
  • Operates with 12V and 24V DC Input
  • Designed for High Volume Applications
  • Up to 41.67 oz-in of Continuous Torque
  • 22 mm Motor Body Diameter
  • Custom Versions are Available
