KNC-PLC-K541

KNC-PLC-K541

KNC-PLC-K205EA-18DT

KNC-PLC-K205EA-18DT

KNC-PLC-K205EX-22DT

Unit Price:
$114.00
Quantity Discount
  • Buy 10 for $107.87 each and save 5%
  • Buy 25 for $102.97 each and save 10%
  • Buy 50 for $99.94 each and save 12%
  • Buy 100 for $96.27 each and save 16%
Inventory:
2
In stock
More Information
Module Type CPU
Input Points 8-14
Input Type Sinking or Sourcing
Output Points 8-14
Output Type Transistor
Rated Voltage 24 VDC
Analog Input N/A
Analog Output N/A
COM Ports Micro USB, RS485
Interested in large quantity discount?

Product Information

The PLC-K205E series provides special I/O functions, a Micro USB (USB 2.0) programming port, 4 high-speed counters, 3 high-speed pulse outputs, two RS485 communication ports, integrated digital input and output channels, and more. The high speed counters come in 10 different operation modes, support a single-phase frequency up to 50 KHz, and a dual-phase (A/B phase) frequency up to 50 KHz. In the 10 different modes, each counter has its own inputs for clock, direction control, start and reset, and has a 32-bit present value. The built-in high-speed pulse outputs can reach a maximum frequency of 50 KHz, and support PWM. The free KincoBuilder software provides absolute and relative positioning, homing, jogging, and quick stop instructions. The PLC-K205E series is an ideal hub for data processing with field devices, such as temperature modules, servo drives, field busses and more.

Note: It is highly recommended to purchase a Micro USB Cable, AAUSB-ABMICRO-6, to properly connect to the HMI/Computer.

  • Four High Speed Counters
  • Modbus RTU Networking (Master/Slave)
  • Real Time Clock
  • 3 Pulse Train Outputs / Pulse Width Modulation
  • Transistor Output
  • Multiple Communication Ports: 1 Micro USB, 2 RS485
  • Rated Input Voltage DC 24V
  • 8 Direct Input, 8 Direct Output, and 6 Direct Input/Output
  • 20 Modes and Inputs of High-Speed Counters

User Manual (PDF)

Spec Sheet (PDF)

Software Download
