KS133-06IV Kinco PLC Expansion Module

KNC-PLC-KS133-06IV

KNC-PLC-K621-16DX

KNC-PLC-K621-16DX

KNC-PLC-K621-08DX

Unit Price:
$53.00
Quantity Discount
  • Buy 10 for $49.73 each and save 6%
  • Buy 25 for $47.47 each and save 10%
  • Buy 50 for $46.07 each and save 13%
  • Buy 100 for $44.60 each and save 16%
Inventory:
0
Out of Stock
More Information
Module Type Expansion Module, Discrete Inputs
Input Points 8
Input Type Sinking or Sourcing
Output Points N/A
Output Type N/A
COM Ports N/A
Interested in large quantity discount?

Product Information

The PLC-K621 series of Discrete Input Expansion Modules are offered with 8 inputs. These modules are attached to the PLC-K6 CPUs to expand beyond the onboard inputs. The PLC-K6 CPU series can handle up to 264 I/O points with a maximum of 14 expansion modules. If a user were to select the PLC-K6, equipped with 40 I/O points, and an additional 14 PLC-K621- 16DX units, the user would achieve the maximum 264 I/O points within the constraint of 6 expansion modules. The PLC-K621-__DX modules come with the option to either sink or source the inputs; each input is rated for 3.5 mA. All modules are opto-isolated so units are not damaged.

  • 8 Inputs
  • Sinking or Sourcing Configuration
  • Rated for 3.5 mA @ 24 VDC
  • Inputs are Opto-isolated
  • LED Display to Monitor Running Conditions
  • Easy Maintenance and Installation

Software User Manual (PDF)

Spec Sheet (PDF)

Software Download
