KNC-PLC-K623-08DR

Unit Price:
$60.00
Quantity Discount
  • Buy 10 for $56.29 each and save 6%
  • Buy 25 for $53.73 each and save 10%
  • Buy 50 for $52.15 each and save 13%
  • Buy 100 for $50.32 each and save 16%
Inventory:
0
Out of Stock
More Information
Module Type Expansion Module, Discrete I/O
Input Points 4
Input Type Sinking or Sourcing
Output Points 4
Output Type Relay
Interested in large quantity discount?

Product Information

The KNC-PLC-K623 Discrete Input and Output Expansion Modules are offered in Relay outputs and sinking or sourcing inputs. These units come with 4 inputs and 4 outputs. These units are ideal to expand beyond the onboard inputs and outputs of the KNC-PLC-K6 CPUs, which can handle up to 264 I/O points with a maximum of 14 expansion modules. The inputs are rated for 3.5 mA and can be configured for either sourcing or sinking. The relay outputs are rated for 2 A @ 30 VDC or 250 VAC, and are great for switching on and off high load devices AC or DC devices, particularly AC or DC motors.

  • 4 Inputs and 4 Outputs
  • Inputs Can be Configured to Sink or Source
  • Relay Outputs
  • Inputs are Opto-Isolated
  • LED Display to Monitor Running Conditions
  • Easy Maintenance and Installation

Software User Manual (PDF)

Spec Sheet (PDF)

Software Download
