LRM23

LRM23 | Anaheim Automation, Inc.

Information

The LRM23 Series is a Precision Rod Actuator with a maximum load capacity of 360 pounds. This rod actuator is powered by a linear step motor, boasts speeds up to 1.2in/s, and the stroke lengths up to 12in.

  • 68mm Square
  • Push Pull Actuator
  • Max Load up to 360lb
  • 1.8° Step Angle
  • Stroke Length up to 12in
  • Multiple Lead Screw Options
  • Designed and Built in the USA
Item Stroke Length (in) Max Speed (in/sec) Travel Per Step (mm) Screw Lead (in) Load Capacity (lbs) Price (USD) Add to Cart
Sort by Name LRM23-12-206A Stroke Length (in) 12 Max Speed (in/sec) 0.375 Travel Per Step (mm) 0.000313 Screw Lead (in) 0.0625 Load Capacity (lbs) 360 N/A Call Us
Sort by Name LRM23-12-2063 Stroke Length (in) 12 Max Speed (in/sec) 0.6 Travel Per Step (mm) 0.0005 Screw Lead (in) 0.1 Load Capacity (lbs) 225 N/A Call Us
Sort by Name LRM23-12-2061 Stroke Length (in) 12 Max Speed (in/sec) 1.2 Travel Per Step (mm) 0.001 Screw Lead (in) 0.2 Load Capacity (lbs) 110 N/A Call Us
Sort by Name LRM23-12-104A Stroke Length (in) 12 Max Speed (in/sec) 0.375 Travel Per Step (mm) 0.000313 Screw Lead (in) 0.0625 Load Capacity (lbs) 360 N/A Call Us
Sort by Name LRM23-12-1043 Stroke Length (in) 12 Max Speed (in/sec) 0.6 Travel Per Step (mm) 0.0005 Screw Lead (in) 0.1 Load Capacity (lbs) 225 N/A Call Us
Sort by Name LRM23-12-1041 Stroke Length (in) 12 Max Speed (in/sec) 1.2 Travel Per Step (mm) 0.001 Screw Lead (in) 0.2 Load Capacity (lbs) 110 N/A Call Us
Sort by Name LRM23-06-206A Stroke Length (in) 6 Max Speed (in/sec) 0.375 Travel Per Step (mm) 0.000313 Screw Lead (in) 0.0625 Load Capacity (lbs) 360 N/A Call Us
Sort by Name LRM23-06-2063 Stroke Length (in) 6 Max Speed (in/sec) 0.6 Travel Per Step (mm) 0.0005 Screw Lead (in) 0.1 Load Capacity (lbs) 225 Price (USD) $666.00
Sort by Name LRM23-06-2061 Stroke Length (in) 6 Max Speed (in/sec) 1.2 Travel Per Step (mm) 0.001 Screw Lead (in) 0.2 Load Capacity (lbs) 110 N/A Call Us
Sort by Name LRM23-06-104A Stroke Length (in) 6 Max Speed (in/sec) 0.375 Travel Per Step (mm) 0.000313 Screw Lead (in) 0.0625 Load Capacity (lbs) 360 N/A Call Us
Sort by Name LRM23-06-1043 Stroke Length (in) 6 Max Speed (in/sec) 0.6 Travel Per Step (mm) 0.0005 Screw Lead (in) 0.1 Load Capacity (lbs) 225 N/A Call Us
Sort by Name LRM23-06-1041 Stroke Length (in) 6 Max Speed (in/sec) 1.2 Travel Per Step (mm) 0.001 Screw Lead (in) 0.2 Load Capacity (lbs) 110 N/A Call Us
Loading...

Additional Information
