PSESMB-0350-1-24V-14.6A

PSESMB-0350-1-24V-14.6A

PSESMB-0350-1-48V-7.3A

PSESMB-0350-1-48V-7.3A

PSESMB-0350-1-36V-9.7A

Unit Price:
$77.00
Quantity Discount
  • Buy 10 for $63.60 each and save 17%
  • Buy 25 for $54.17 each and save 30%
  • Buy 50 for $47.32 each and save 39%
  • Buy 100 for $41.17 each and save 47%
Inventory:
7
In stock
More Information
Input Voltage (VAC) 90-132VAC/180-264 VAC selected by switch, Single Phase, 47-63Hz
Output Voltage (V) 36
Total Power (W) 350
Interested in large quantity discount?

Product Information

Anaheim Automation's PSESMB series is a cost-effective choice for your power supply requirements. This power supply provides up to 350Watts of power at voltages of 24, 36 and 48VDC with a switch selectable input range of 90-132VAC to 180-264VAC. Each power supply is equipped with an LED indicator for power on in addition to short-circuit, overload, and over voltage protection features. Compact in size and affordably priced, they provide up to 89° efficiency, high reliability, and a long lifetime.

  • AC Input Range Selectable By Switch
  • Short Circuit/Overload/ Over Voltage/Over Temperature Protection
  • Forced Air Cooling By Built-in DC Fan
  • Withstand 300VAC Surge Input For 5 Seconds
  • Built-in Cooling Fan ON-OFF Control
  • Built-in Constant Current Limiting Circuit
  • LED Indicator for Power On
  • 100% Full Load Burn-in Test
  • 5G Anti-Vibration Capability
  • No Load Power Consumption Less Than 0.75W
  • Operating Temperature Range: -25°C to 70°C With Full Load

Spec Sheet (PDF)
