TSFCA25-150-21-023-LW6-A022
| Bipolar RMS Current (A) | 0.23 |
|---|---|
| Bipolar RMS Voltage (V) | 12 |
| Travel Per Step (mm) | 0.0417 |
| # of Lead Wires | 4 |
| Weight (lbs) | 0.08 |
| Maximum Force (lbs) | 3.37 |
| Motor Length (in) | 2.637 |
| Screw Length (in) | 0.87 |
Interested in large quantity discount?
Product Information
The TSFCA25 Series Captive Linear Actuators are the perfect choice for cost effective linear motion. The stepper motor internally converts rotary motion to linear motion via a rotating nut and a leadscrew. This actuator eliminates the need for other rotary-to-linear conversions such as belt and pulleys, rack and pinions, or external ball screws. Motion designs can be simplified, production costs lowered and product life enhanced. The motors can be customized to fit your machine requirements. The winding can be customized to perfectly match your voltage, current, and maximum operating speed. Special screw modifications, cables and connectors are also available upon request.
- Permanent Magnet Stepper Motor Actuator
- Precise Motion at a Low Cost
- 10 Newton of Force
- 25mm Diameter
- Actuator Extends out of the Motor
- Inexpensively Create Linear Travel
.png)
.png)
.png)
