ACP-M-3IK15A-CU

ACP-M-3IK15A-CU

ACP-M-4IK25A-AU

ACP-M-4IK25A-AU

ACP-M-3IK15A-CUV

1pc Price:
$116.00
Quantity Discount
  • Buy 10 for $112.21 each and save 3%
  • Buy 25 for $105.44 each and save 9%
  • Buy 50 for $102.93 each and save 11%
  • Buy 100 for $101.37 each and save 13%
Inventory:
1
More Information
Frame Size (mm) 70
Rated Torque (oz-in) 12
Rated Speed (RPM) Variable
Starting Torque (oz-in) 10
Frequency (Hz) 60
Input Voltage (VAC) 220
Current (A) 0.28
Output Power (W) 15
Capacitor (uF / V) 1.2/450
Mounting Type P, U
Shaft Diameter (mm) 6
Weight (lbs) 2.31
Single or Three Phase Single
Interested in large quantity discount?

Product Information

ACP-M-3xK15A motor series provide users with a simple, cost-effective solution. ACP-M-3xK15A motors operate at 120/220VAC, so there is no need for a transformer; just hook up and go!

If your application requires speed control, these ACP-M-3RK15A-xUV variable speed gearmotors require an ACP-US-3I15A-xL Variable Speed Motor.

Note: ACP-M Induction Motors are LTSOH (Limited to Stock on Hand).

  • Brushless Design for Long Life and Quiet Operation
  • 120/220 VAC Input
  • Single-Phase Operation
  • Rated for Continuous Operation
  • Self-Starting
  • High Starting Torque for High Inertial Loads
  • Direct Replacement for Some Panasonic AC Induction Motors
  • Cost-Effective Solution
  • Long Life and Highly Reliable
  • Can be Customized for
    • Maximum Speed
    • Winding Current
    • Shaft Options
    • Cables and Connectors
    • Clutch and/or Brake
    • Terminal Box
  • CE Certified

Mating Receptacle: ELR-06V

Mating Pin: SLM-41T-P1.3E

Single Phase Wiring

3 Phase Wiring

3D PDF

.STEP File (.RAR File)

User Manual (PDF)
