BSC-AAM-SFKR-008-01-RC7-P1-1000
| Screw Length | 1000 |
|---|---|
| Helix | Right |
| d | 8 |
| I | 1 |
| D | 14 |
| A | 27 |
| B | 4 |
| L | 16 |
| W | 21 |
| H | 18 |
| X | 3.4 |
| Y | - |
| Z | - |
| Q | - |
| n | 1x4 |
| Ca | 161 |
| Coa | 403 |
| Screw Diameter | 8 |
Interested in large quantity discount?
Product Information
The SFKx-008 Series Ball Screws have a diameter of 8mm with a lead ranging from 1mm to 2.5mm. The assembly provides a dynamic force up to 222 Kgf and a static force up to 458 Kgf. The maximum length for this screw is 1,000mm. All ball screws listed are cut to length. End machining available. Submit your drawing to sales@anaheimautomation.com
For assistance in selecting the appropriate ball screw for your application, please fill out our Ball Screw Application Sheet and submit it to our sales department.
- 8mm Diameter with 1mm-2.5mm Lead
- Dynamic Force: Up to 222 Kgf
- Static Load: Up to 458 Kgf
- Screw Lengths Up to 1,000mm
- Custom Screw Sizes Available
- Standard is C7 Accuracy and P1 Preload
- Other Accuracies and Preloads Available Upon Request
