ACWGM090-090-140-110-1550-R18

ACWGM090-090-140-110-1550-R18

EMJ-02APA24

EMJ-02APA24

EMG-15APB22

1pc Price:
$953.00
Inventory:
1
More Information
Rated Torque (oz-in) 1013
Rated Power (Watts) 1500
Rated Speed (RPM) 2000
Max Speed (rpm) 3000
Rated Current (Arms) 8.2
Voltage 220 VAC
Brake No
Inertia (oz-in-sec2) 0.2605
Torque Constant KT (oz-in/A) 157.1
Resistance (ohms) 0.65
Length (mm) 240
Weight (lbs) 21.6
Interested in large quantity discount?

Product Information

EMG-15APB22 is LTSOH (Limited to Stock on Hand)

Anaheim Automation’s Digital AC Servo Motors offer a simple solution to servo applications involving speed and positioning control. The AC EMG-15 Servo Motor comes standard with a 2,500 Pulses Per Revolution (PPR) Incremental Encoder, runs at a maximum speed of 3,000 RPM, provides peak values up to 300% of the rated torque and current values, and has a rated torque of 1,014 oz-in with a 1.5 kWatt power rating. These enclosed and self-cooled motors also provide longer motor life and higher reliability. The EMG-15 AC Servo Motors enable industrial motion control applications with medium inertia to attain a great combination of speed and positioning functionality.

  • Rated Torque of 1,014 oz-in
  • Medium Inertia to Maximize Torque
  • Peak Torque up to 300% of Rated Torque
  • Peak Current up to 300% of Rated Current
  • Speed of up to 3,000 RPM
  • 2,500 PPR Incremental Encoder Attached
  • Enclosed and Self-Cooled
  • Power Rating up to 1.5 kWatts
  • Oil Seal and Optional Brake
  • Long Life and Highly Reliable
  • Neodymium-Iron-Boron Magnets (NdFeB)
  • CE Certified

Spec Sheet (PDF)
