GBPH-150x-NP

GBPH-150x-NP | Anaheim Automation, Inc.

Information

The GBPH-150x-NP Series is an In-Line Planetary Gearbox line that offers great prices without sacrificing precision and quality! The GBPH-150x-NP Series is designed for motion control applications requiring moderate backlash and stiffness. This series will match most NEMA 58 servo or stepping motors. Features include standard backlash as low as 6 arc-min, 37 gear ratios from 3 to 1000 for rated torque up to 4,957 in-lbs (79,312 oz-in), (model dependent), and a patented precision clamping system and lifetime lubrication.

  • Compatable with NEMA Size 58 Motors
  • Backlash as Low as 5 arc-min
  • Gear Ratios from 3 to 1000
  • Available in 1, 2 and 3 Stage Models
  • Operating Temperature of -15° to 90°C
  • Rated Output Torque 4213 to 4957 in-lb
Item Gear Ratio (X:1) Rated Output Torque (in-lbs) Max Output Torque (in-lbs) Backlash Maximum (arc-min) Rated Speed (RPM) Stages Efficiency (%) Torsional Rigidity (Nm/arcmin) L2 Length (mm) Weight (lbs) 1pc Price (USD) Add to Cart
Sort by Name GBPH-1503-NP-1000 Gear Ratio (X:1) 1000 Rated Output Torque (in-lbs) 4602 Max Output Torque (in-lbs) 13806 Backlash Maximum (arc-min) 10 Rated Speed (RPM) 3000 Stages 3 Efficiency (%) 95 Torsional Rigidity (Nm/arcmin) 48 L2 Length (mm) 170 Weight (lbs) 48.50 1pc Price (USD) $2,162.00 Call Us Contact Us
Sort by Name GBPH-1503-NP-500 Gear Ratio (X:1) 500 Rated Output Torque (in-lbs) 4602 Max Output Torque (in-lbs) 13806 Backlash Maximum (arc-min) 10 Rated Speed (RPM) 3000 Stages 3 Efficiency (%) 95 Torsional Rigidity (Nm/arcmin) 48 L2 Length (mm) 170 Weight (lbs) 48.50 1pc Price (USD) $2,162.00 Call Us Contact Us
Sort by Name GBPH-1503-NP-490 Gear Ratio (X:1) 490 Rated Output Torque (in-lbs) 4602 Max Output Torque (in-lbs) 13806 Backlash Maximum (arc-min) 10 Rated Speed (RPM) 3000 Stages 3 Efficiency (%) 95 Torsional Rigidity (Nm/arcmin) 48 L2 Length (mm) 170 Weight (lbs) 48.50 1pc Price (USD) $2,162.00 Call Us Contact Us
Sort by Name GBPH-1503-NP-400 Gear Ratio (X:1) 400 Rated Output Torque (in-lbs) 4602 Max Output Torque (in-lbs) 13806 Backlash Maximum (arc-min) 10 Rated Speed (RPM) 3000 Stages 3 Efficiency (%) 95 Torsional Rigidity (Nm/arcmin) 48 L2 Length (mm) 170 Weight (lbs) 48.50 1pc Price (USD) $2,162.00 Call Us Contact Us
Sort by Name GBPH-1503-NP-300 Gear Ratio (X:1) 300 Rated Output Torque (in-lbs) 4602 Max Output Torque (in-lbs) 13806 Backlash Maximum (arc-min) 10 Rated Speed (RPM) 3000 Stages 3 Efficiency (%) 95 Torsional Rigidity (Nm/arcmin) 48 L2 Length (mm) 170 Weight (lbs) 48.50 1pc Price (USD) $2,162.00 Call Us Contact Us
Sort by Name GBPH-1503-NP-250 Gear Ratio (X:1) 250 Rated Output Torque (in-lbs) 4602 Max Output Torque (in-lbs) 13806 Backlash Maximum (arc-min) 10 Rated Speed (RPM) 3000 Stages 3 Efficiency (%) 95 Torsional Rigidity (Nm/arcmin) 48 L2 Length (mm) 170 Weight (lbs) 48.50 1pc Price (USD) $2,162.00 Call Us Contact Us
Sort by Name GBPH-1503-NP-245 Gear Ratio (X:1) 245 Rated Output Torque (in-lbs) 4602 Max Output Torque (in-lbs) 13806 Backlash Maximum (arc-min) 10 Rated Speed (RPM) 3000 Stages 3 Efficiency (%) 95 Torsional Rigidity (Nm/arcmin) 48 L2 Length (mm) 170 Weight (lbs) 48.50 1pc Price (USD) $2,162.00 Call Us Contact Us
Sort by Name GBPH-1503-NP-196 Gear Ratio (X:1) 196 Rated Output Torque (in-lbs) 4602 Max Output Torque (in-lbs) 13806 Backlash Maximum (arc-min) 10 Rated Speed (RPM) 3000 Stages 3 Efficiency (%) 95 Torsional Rigidity (Nm/arcmin) 48 L2 Length (mm) 170 Weight (lbs) 48.50 1pc Price (USD) $2,162.00 Call Us Contact Us
Sort by Name GBPH-1503-NP-175 Gear Ratio (X:1) 175 Rated Output Torque (in-lbs) 4602 Max Output Torque (in-lbs) 13806 Backlash Maximum (arc-min) 10 Rated Speed (RPM) 3000 Stages 3 Efficiency (%) 95 Torsional Rigidity (Nm/arcmin) 48 L2 Length (mm) 170 Weight (lbs) 48.50 1pc Price (USD) $2,162.00 Call Us Contact Us
Sort by Name GBPH-1503-NP-160 Gear Ratio (X:1) 160 Rated Output Torque (in-lbs) 4602 Max Output Torque (in-lbs) 13806 Backlash Maximum (arc-min) 10 Rated Speed (RPM) 3000 Stages 3 Efficiency (%) 95 Torsional Rigidity (Nm/arcmin) 48 L2 Length (mm) 170 Weight (lbs) 48.50 1pc Price (USD) $2,162.00 Call Us Contact Us
Sort by Name GBPH-1503-NP-147 Gear Ratio (X:1) 147 Rated Output Torque (in-lbs) 4602 Max Output Torque (in-lbs) 13806 Backlash Maximum (arc-min) 10 Rated Speed (RPM) 3000 Stages 3 Efficiency (%) 95 Torsional Rigidity (Nm/arcmin) 48 L2 Length (mm) 170 Weight (lbs) 48.50 1pc Price (USD) $2,162.00 Call Us Contact Us
Sort by Name GBPH-1503-NP-125 Gear Ratio (X:1) 125 Rated Output Torque (in-lbs) 4602 Max Output Torque (in-lbs) 13806 Backlash Maximum (arc-min) 10 Rated Speed (RPM) 3000 Stages 3 Efficiency (%) 95 Torsional Rigidity (Nm/arcmin) 48 L2 Length (mm) 170 Weight (lbs) 48.50 1pc Price (USD) $2,162.00 Call Us Contact Us
Sort by Name GBPH-1503-NP-112 Gear Ratio (X:1) 112 Rated Output Torque (in-lbs) 4602 Max Output Torque (in-lbs) 13806 Backlash Maximum (arc-min) 10 Rated Speed (RPM) 3000 Stages 3 Efficiency (%) 95 Torsional Rigidity (Nm/arcmin) 48 L2 Length (mm) 170 Weight (lbs) 48.50 1pc Price (USD) $2,162.00 Call Us Contact Us
Sort by Name GBPH-1503-NP-080 Gear Ratio (X:1) 80 Rated Output Torque (in-lbs) 4602 Max Output Torque (in-lbs) 13806 Backlash Maximum (arc-min) 10 Rated Speed (RPM) 3000 Stages 3 Efficiency (%) 94 Torsional Rigidity (Nm/arcmin) 48 L2 Length (mm) 170 Weight (lbs) 48.50 1pc Price (USD) $2,162.00 Call Us Contact Us
Sort by Name GBPH-1503-NP-075 Gear Ratio (X:1) 75 Rated Output Torque (in-lbs) 4602 Max Output Torque (in-lbs) 13806 Backlash Maximum (arc-min) 10 Rated Speed (RPM) 3000 Stages 3 Efficiency (%) 94 Torsional Rigidity (Nm/arcmin) 48 L2 Length (mm) 170 Weight (lbs) 48.50 1pc Price (USD) $2,162.00 Call Us Contact Us
Sort by Name GBPH-1503-NP-064 Gear Ratio (X:1) 64 Rated Output Torque (in-lbs) 4602 Max Output Torque (in-lbs) 13806 Backlash Maximum (arc-min) 10 Rated Speed (RPM) 3000 Stages 3 Efficiency (%) 94 Torsional Rigidity (Nm/arcmin) 48 L2 Length (mm) 170 Weight (lbs) 48.50 1pc Price (USD) $2,162.00 Call Us Contact Us
Sort by Name GBPH-1503-NP-048 Gear Ratio (X:1) 48 Rated Output Torque (in-lbs) 4602 Max Output Torque (in-lbs) 13806 Backlash Maximum (arc-min) 10 Rated Speed (RPM) 3000 Stages 3 Efficiency (%) 94 Torsional Rigidity (Nm/arcmin) 48 L2 Length (mm) 170 Weight (lbs) 48.50 1pc Price (USD) $2,162.00 Call Us Contact Us
Sort by Name GBPH-1502-NP-100 Gear Ratio (X:1) 100 Rated Output Torque (in-lbs) 4603 Max Output Torque (in-lbs) 13808 Backlash Maximum (arc-min) 10 Rated Speed (RPM) 3000 Stages 2 Efficiency (%) 94 Torsional Rigidity (Nm/arcmin) 48 L2 Length (mm) 170 Weight (lbs) 37.48 1pc Price (USD) $1,907.00 Call Us Contact Us
Sort by Name GBPH-1502-NP-070 Gear Ratio (X:1) 70 Rated Output Torque (in-lbs) 4603 Max Output Torque (in-lbs) 13808 Backlash Maximum (arc-min) 10 Rated Speed (RPM) 3000 Stages 2 Efficiency (%) 94 Torsional Rigidity (Nm/arcmin) 48 L2 Length (mm) 170 Weight (lbs) 37.48 1pc Price (USD) $1,907.00 Call Us Contact Us
Sort by Name GBPH-1502-NP-050 Gear Ratio (X:1) 50 Rated Output Torque (in-lbs) 4744 Max Output Torque (in-lbs) 14232 Backlash Maximum (arc-min) 10 Rated Speed (RPM) 3000 Stages 2 Efficiency (%) 94 Torsional Rigidity (Nm/arcmin) 48 L2 Length (mm) 170 Weight (lbs) 37.48 1pc Price (USD) $1,907.00 Call Us Contact Us
Sort by Name GBPH-1502-NP-049 Gear Ratio (X:1) 49 Rated Output Torque (in-lbs) 4602 Max Output Torque (in-lbs) 13806 Backlash Maximum (arc-min) 10 Rated Speed (RPM) 3000 Stages 2 Efficiency (%) 94 Torsional Rigidity (Nm/arcmin) 48 L2 Length (mm) 170 Weight (lbs) 37.48 1pc Price (USD) $1,907.00 Call Us Contact Us
Sort by Name GBPH-1502-NP-040 Gear Ratio (X:1) 40 Rated Output Torque (in-lbs) 4957 Max Output Torque (in-lbs) 14870 Backlash Maximum (arc-min) 10 Rated Speed (RPM) 3000 Stages 2 Efficiency (%) 94 Torsional Rigidity (Nm/arcmin) 48 L2 Length (mm) 170 Weight (lbs) 37.48 1pc Price (USD) $1,907.00 Call Us Contact Us
Sort by Name GBPH-1502-NP-035 Gear Ratio (X:1) 35 Rated Output Torque (in-lbs) 4603 Max Output Torque (in-lbs) 13808 Backlash Maximum (arc-min) 10 Rated Speed (RPM) 3000 Stages 2 Efficiency (%) 94 Torsional Rigidity (Nm/arcmin) 48 L2 Length (mm) 118 Weight (lbs) 37.48 1pc Price (USD) $1,907.00 Call Us Contact Us
Sort by Name GBPH-1502-NP-030 Gear Ratio (X:1) 30 Rated Output Torque (in-lbs) 4213 Max Output Torque (in-lbs) 12639 Backlash Maximum (arc-min) 10 Rated Speed (RPM) 3000 Stages 2 Efficiency (%) 94 Torsional Rigidity (Nm/arcmin) 48 L2 Length (mm) 118 Weight (lbs) 37.48 1pc Price (USD) $1,907.00 Call Us Contact Us
Sort by Name GBPH-1502-NP-028 Gear Ratio (X:1) 28 Rated Output Torque (in-lbs) 4957 Max Output Torque (in-lbs) 13808 Backlash Maximum (arc-min) 10 Rated Speed (RPM) 3000 Stages 2 Efficiency (%) 94 Torsional Rigidity (Nm/arcmin) 48 L2 Length (mm) 118 Weight (lbs) 37.48 1pc Price (USD) $1,907.00 Call Us Contact Us
Sort by Name GBPH-1502-NP-025 Gear Ratio (X:1) 25 Rated Output Torque (in-lbs) 4957 Max Output Torque (in-lbs) 14870 Backlash Maximum (arc-min) 10 Rated Speed (RPM) 3000 Stages 2 Efficiency (%) 94 Torsional Rigidity (Nm/arcmin) 48 L2 Length (mm) 118 Weight (lbs) 37.48 1pc Price (USD) $1,907.00 Call Us Contact Us
Sort by Name GBPH-1502-NP-021 Gear Ratio (X:1) 21 Rated Output Torque (in-lbs) 4603 Max Output Torque (in-lbs) 12639 Backlash Maximum (arc-min) 10 Rated Speed (RPM) 3000 Stages 2 Efficiency (%) 94 Torsional Rigidity (Nm/arcmin) 48 L2 Length (mm) 118 Weight (lbs) 37.48 1pc Price (USD) $1,907.00 Call Us Contact Us
Sort by Name GBPH-1502-NP-020 Gear Ratio (X:1) 20 Rated Output Torque (in-lbs) 4957 Max Output Torque (in-lbs) 14870 Backlash Maximum (arc-min) 10 Rated Speed (RPM) 3000 Stages 2 Efficiency (%) 94 Torsional Rigidity (Nm/arcmin) 48 L2 Length (mm) 118 Weight (lbs) 37.48 1pc Price (USD) $1,907.00 Call Us Contact Us
Sort by Name GBPH-1502-NP-016 Gear Ratio (X:1) 16 Rated Output Torque (in-lbs) 4957 Max Output Torque (in-lbs) 14870 Backlash Maximum (arc-min) 10 Rated Speed (RPM) 3000 Stages 2 Efficiency (%) 94 Torsional Rigidity (Nm/arcmin) 48 L2 Length (mm) 118 Weight (lbs) 37.48 1pc Price (USD) $1,907.00 Call Us Contact Us
Sort by Name GBPH-1502-NP-015 Gear Ratio (X:1) 15 Rated Output Torque (in-lbs) 4957 Max Output Torque (in-lbs) 14870 Backlash Maximum (arc-min) 10 Rated Speed (RPM) 3000 Stages 2 Efficiency (%) 94 Torsional Rigidity (Nm/arcmin) 48 L2 Length (mm) 118 Weight (lbs) 37.48 1pc Price (USD) $1,907.00 Call Us Contact Us
Sort by Name GBPH-1502-NP-012 Gear Ratio (X:1) 12 Rated Output Torque (in-lbs) 4213 Max Output Torque (in-lbs) 12639 Backlash Maximum (arc-min) 10 Rated Speed (RPM) 3000 Stages 2 Efficiency (%) 94 Torsional Rigidity (Nm/arcmin) 48 L2 Length (mm) 118 Weight (lbs) 37.48 1pc Price (USD) $1,907.00 Call Us Contact Us
Sort by Name GBPH-1502-NP-009 Gear Ratio (X:1) 9 Rated Output Torque (in-lbs) 4213 Max Output Torque (in-lbs) 12639 Backlash Maximum (arc-min) 10 Rated Speed (RPM) 3000 Stages 2 Efficiency (%) 97 Torsional Rigidity (Nm/arcmin) 48 L2 Length (mm) 118 Weight (lbs) 37.48 1pc Price (USD) $1,907.00 Call Us Contact Us
Sort by Name GBPH-1501-NP-010 Gear Ratio (X:1) 10 Rated Output Torque (in-lbs) 4213 Max Output Torque (in-lbs) 12639 Backlash Maximum (arc-min) 6 Rated Speed (RPM) 3000 Stages 1 Efficiency (%) 97 Torsional Rigidity (Nm/arcmin) 48 L2 Length (mm) 66 Weight (lbs) 28.66 1pc Price (USD) $1,643.00 Call Us Contact Us
Sort by Name GBPH-1501-NP-007 Gear Ratio (X:1) 7 Rated Output Torque (in-lbs) 4603 Max Output Torque (in-lbs) 13808 Backlash Maximum (arc-min) 6 Rated Speed (RPM) 3000 Stages 1 Efficiency (%) 97 Torsional Rigidity (Nm/arcmin) 48 L2 Length (mm) 66 Weight (lbs) 28.66 1pc Price (USD) $1,643.00 Call Us Contact Us
Sort by Name GBPH-1501-NP-005 Gear Ratio (X:1) 5 Rated Output Torque (in-lbs) 4744 Max Output Torque (in-lbs) 14232 Backlash Maximum (arc-min) 6 Rated Speed (RPM) 3000 Stages 1 Efficiency (%) 97 Torsional Rigidity (Nm/arcmin) 48 L2 Length (mm) 66 Weight (lbs) 28.66 1pc Price (USD) $1,643.00 Call Us Contact Us
Sort by Name GBPH-1501-NP-004 Gear Ratio (X:1) 4 Rated Output Torque (in-lbs) 4957 Max Output Torque (in-lbs) 14870 Backlash Maximum (arc-min) 6 Rated Speed (RPM) 3000 Stages 1 Efficiency (%) 97 Torsional Rigidity (Nm/arcmin) 48 L2 Length (mm) 66 Weight (lbs) 28.66 1pc Price (USD) $1,643.00 Call Us Contact Us
Sort by Name GBPH-1501-NP-003 Gear Ratio (X:1) 3 Rated Output Torque (in-lbs) 4213 Max Output Torque (in-lbs) 12639 Backlash Maximum (arc-min) 6 Rated Speed (RPM) 3000 Stages 1 Efficiency (%) 97 Torsional Rigidity (Nm/arcmin) 48 L2 Length (mm) 66 Weight (lbs) 28.66 1pc Price (USD) $1,643.00 Call Us Contact Us
Loading...

Additional Information



Motor Interface codes shown in this chart represent "suffixes" for complete gearbox part numbers. Choose a gearbox Item from the product table above, and you will be able to select the appropriate motor interface/suffix on the individual product page.

For custom input dimensions, or non-Anaheim Automation motors, fill out our  Gearbox Mounting Form  and submit it to our Sales Engineers at sales@anaheimautomation.com
