Unit Price:
$114.00
Quantity Discount
  • Buy 10 for $107.86 each and save 5%
  • Buy 25 for $102.96 each and save 10%
  • Buy 50 for $94.41 each and save 17%
  • Buy 100 for $87.33 each and save 23%
Inventory:
8
In stock
More Information
Module Type Expansion Module, Analog Outputs
Input Points N/A
Input Type N/A
Output Points 2
Output Type 0-20mA, 4-20mA, 1-5VDC, 0-10VDC
Analog Output 2
Interested in large quantity discount?

Product Information

NOTE: The KNC-PLC-K532-02IV units have been discontinued and are now LTSOH (Limited to Stock on Hand). We recommend the KNC-PLC-K632-02IV as a replacement.

The PLC-K532-02IV is an Analog Output Expansion Module that reads in a digital value from the PLC and outputs either a voltage or current that reflects that digital value. This unit has a 12-bit digital output resolution allowing the user to increment in 976μV or 3.9μA steps. The PLC-K532-02IV can output a current range of 0-20mA or 4-20mA, and a voltage range of 1-5VDC or 0-10VDC. The K531 series has an accuracy of ±0.5% to ensure a precise reading. These modules are attached to the PLC-K5 CPU series to provide analog output capabilities. Up to 6 of the analog output modules can be attached to the K5 series CPUs, allowing for a maximum of 12 analog outputs or 14 analog outputs if using the PLC-K506EA-30AT.

  • Current and Voltage Outputs
  • Provides Wide Output Range
  • Up to 6 Analog Output Modules in One PLC-K5 System
  • 12-bit Conversion for High-Resolution Measurement
  • Very Reliable ±0.3% Error
