KNC-PLC-K533-04IV

Unit Price:
$133.00
Quantity Discount
  • Buy 10 for $125.72 each and save 5%
  • Buy 25 for $120.00 each and save 10%
  • Buy 50 for $110.96 each and save 17%
  • Buy 100 for $101.62 each and save 24%
Inventory:
8
In stock
More Information
Module Type Expansion Module, Analog I/O
Input Points 2
Input Type 0-20mA, 4-20mA, 1-5VDC, 0-10VDC
Output Points 2
Output Type 0-20mA, 4-20mA, 1-5VDC, 0-10VDC
Analog Input 2
Analog Output 2
Interested in large quantity discount?

Product Information

NOTE: The KNC-PLC-K533-04IV units have been discontinued and are now LTSOH (Limited to Stock on Hand). We recommend the KNC-PLC-K633-04IV as a replacement.

The PLC-K533-04IV Analog Input/Output Module was designed to do the job of both the PLC-K531 and PLC-K532 series all on one module. The PLC-K533-04IV is equipped with 2 analog inputs and 2 analog outputs. The PLC-K533-04IV performs a 12-bit conversion on the inputs for high-resolution measurement and can be configured to read voltages or currents of different ranges. The current ranges of the analog inputs are 0-20mA or 4-20mA, and the voltage ranges of the analog outputs are 1-5VDC or 0-10VDC. The analog outputs have a 12-bit output resolution allowing the user to increment in 976μV or 3.9μA steps. The current ranges of the analog outputs are; 0-20mA or 4-20mA. The voltage ranges of the analog outputs are 1-5VDC or 0-10VDC. The K533 series has an accuracy of ±0.5% to ensure a precise reading.

  • Current and Voltage Inputs
  • Current and Voltage Outputs
  • Provides Wide Input/Output Range
  • Up to 6 Analog Input/Output Modules in One PLC-K5 System
  • 12-bit Conversion for High-Resolution Measurement
  • Very Reliable ±0.5% Error
