KNC-PLC-K623-08DT
| Module Type | Expansion Module, Discrete I/O |
|---|---|
| Input Points | 4 |
| Input Type | Sinking or Sourcing |
| Output Points | 4 |
| Output Type | Transistor |
Interested in large quantity discount?
Product Information
The KNC-PLC-K623 Discrete Input and Output Expansion Modules are offered in Transistor outputs and sinking or sourcing inputs. These units come with 4 inputs and 4 outputs. These units are ideal to expand beyond the onboard inputs and outputs of the KNC-PLC-K6 CPUs, which can handle up to 264 I/O points with a maximum of 14 expansion modules. The inputs are rated for 3.5 mA and can be configured for either sourcing or sinking. The transistor outputs are rated for 500 mA @ 24 VDC and come only in a sourcing configuration. The transistor output modules are opto-isolated for unit protection.
- 4 Inputs and 4 Outputs
- Inputs Can be Configured to Sink or Source
- Transistor Outputs
- Inputs are Opto-Isolated
- Transistor Outputs are Opto-Isolated
- LED Display to Monitor Running Conditions
- Easy Maintenance and Installation
