Module Type Expansion Module, Discrete I/O
Input Points 8
Input Type Sinking or Sourcing
Output Points 8
Output Type Transistor
Interested in large quantity discount?

Product Information

The KNC-PLC-K623 Discrete Input and Output Expansion Modules are offered in Transistor outputs and sinking or sourcing inputs. These units come with 8 inputs and 8 outputs. These units are ideal to expand beyond the onboard inputs and outputs of the KNC-PLC-K6 CPUs, which can handle up to 264 I/O points with a maximum of 14 expansion modules. The inputs are rated for 3.5 mA and can be configured for either sourcing or sinking. The transistor outputs are rated for 500 mA @ 24 VDC and come only in a sourcing configuration. The transistor output modules are opto-isolated for unit protection.

  • 8 Inputs and 8 Outputs
  • Inputs Can be Configured to Sink or Source
  • Transistor Outputs
  • Inputs are Opto-Isolated
  • Transistor Outputs are Opto-Isolated
  • LED Display to Monitor Running Conditions
  • Easy Maintenance and Installation
