LSI-LS7183N

1pc Price:
$4.00
Quantity Discount
  • Buy 10 for $3.41 each and save 15%
  • Buy 25 for $3.37 each and save 16%
  • Buy 50 for $3.32 each and save 17%
  • Buy 100 for $2.76 each and save 31%
Inventory:
53
More Information
Package Type PDIP
Pin Count 8
Interested in large quantity discount?

Product Information

The LS7183N and LS7184N are CMOS quadrature clock converters. Quadrature clocks derived from optical or magnetic encoders, when applied to the A and B inputs of the LS7183N/LS7184N, are converted to strings of Up Clocks and Down Clocks (LS7183N) or to a Clock and an Up/Down direction control (LS7184N). These outputs can be interfaced directly with standard Up/Down counters for direction and position. This series has a minimum purchase requirement of 10 pieces, regardless of stock.

  • x1, x2 and x4 Resolution
  • Programmable Output Clock Pulse Width
  • Excellent Regulation of Output Pulse Width
  • TTL and CMOS Compatible I/Os
  • +3V to +12V Operation (Vdd - Vss)
  • RoHS Compliant

User Manual (PDF)
