LSI-LS7366R-S
| Package Type | SOIC |
|---|---|
| Pin Count | 14 |
Interested in large quantity discount?
Product Information
LSI-LS7366R is a 32-bit CMOS counter, with direct interface for quadrature clocks from incremental encoders. It also interfaces with the index signals from incremental encoders to perform variety of marker functions. Note: This series has a minimum purchase requirement of 10 pieces, regardless of stock.
- Operating Voltage: 3V to 5.5V (Vdd - Vss)
- 5V Count Frequency: 40MHz, 3V Count Frequency: 20MHz
- 32-bit Counter, Data Register, Output Register, and Comparator
- 8-bit Mode Registers, Instruction Register, and Status Register
- x1, x2, or x4 Mode of Quadrature Counting
- Non-Quadrature Up/Down Counting
- Modulo-N, Non-Recycle, Range-Limit or Free-Running Modes of Counting
- RoHS Compliant
.png)
.png)
User Manual (PDF)
