LSI-LS7366R-TS

Unit Price:
Inventory:
95
In stock
More Information
Package Type TSSOP
Pin Count 14
Interested in large quantity discount?

Product Information

LSI-LS7366R is a 32-bit CMOS counter, with direct interface for quadrature clocks from incremental encoders. It also interfaces with the index signals from incremental encoders to perform variety of marker functions. Note: This series has a minimum purchase requirement of 10 pieces, regardless of stock.

  • Operating Voltage: 3V to 5.5V (Vdd - Vss)
  • 5V Count Frequency: 40MHz, 3V Count Frequency: 20MHz
  • 32-bit Counter, Data Register, Output Register, and Comparator
  • 8-bit Mode Registers, Instruction Register, and Status Register
  • x1, x2, or x4 Mode of Quadrature Counting
  • Non-Quadrature Up/Down Counting
  • Modulo-N, Non-Recycle, Range-Limit or Free-Running Modes of Counting
  • RoHS Compliant

User Manual (PDF)
