MDC020-EVALBD
| Input Range | 6 - 50VDC |
|---|---|
| Max Power (W) | 200 |
| Peak Current (A) | 10 |
| Feedback Loop | --- |
Interested in large quantity discount?
Product Information
The MDC020-EVALBD is a Brushless and Brush DC Speed Controller Evaluation Board that can be used with the MDC020-024031, MBDC020-024031 or MDC020-050101 controller for immediate start-up and testing. Also included are terminal blocks for easier motor connections, onboard switches to control direction and stopping, and a potentiometer to control speed. With an MDC020-024031 or MBDC020-024031 controller, the allowable input voltage range is 8-24VDC; with a continuous output current of 1.5A (3A Peak). With an MDC020-050101 controller, the allowable input voltage range is 6-50VDC; with a continuous output current of 5A (10A Peak).
- Single-Axis System
- Suitable for Use With:
- MDC020-024031
- MDC020-050101
- MBDC020-024031
- RoHS compliant
