The 17L Series High Torque Step Motors offer a great value without sacrificing quality. These motors are designed to offer the highest possible torque while minimizing vibration and audible noise. A broad line of motor windings and stack lengths are available off-the-shelf, or the motors can be customized to fit your machine requirements. We can customize the winding to perfectly match your voltage, current, and maximum torque at operating speeds for maximum flexibility.
See Accessories on this website for optional motor adders, such as encoders, cables and connectors. Gearbox adders are also available, and can be found under Gearboxes. For compatible drivers, consider popular models MBC15081, MBC25081TB.
- Frame Size: NEMA 17
- Holding Torque: 38-77 oz-in.
- Current: 0.7-1.1A
| Item | NEMA Size | Bipolar Torque (oz-in) | Bipolar Series RMS Current (A) | Bipolar Series RMS Voltage (V) | Bipolar Series Inductance Per Phase (mH) | Bipolar Series Resistance Per Phase (ohm) | Rotor Inertia (oz-in-sec2) | # of Lead Wires | Shaft | Weight (lbs) | Length (in) | 1pc Price (USD) | Add to Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 17L202D-LW8 | 17 | 77 | 0.7 | 4.7 | 22 | 11 | 0.0007 | 8 | Double | 0.76 | 1.77 | $119.00 |
Notes: Custom leadwires, cables, connectors, and windings are available upon request.
Additional Information
.png)
.png)
17L0
.png)
17L0
.png)
17L0
.png)
17L1
17L1
17L2
17L2
