ACW140-100-192-110-1550
| Frame Size (mm) | 100 |
|---|---|
| Rated Torque (oz-in) | 122.21 |
| Rated Speed (RPM) | 1550 |
| Starting Torque (oz-in) | 107.63 |
| Frequency (Hz) | 60 |
| Input Voltage (VAC) | 110 |
| Current (A) | 2.3 |
| Output Power (W) | 140 |
| Capacitor (uF / V) | 30/250 |
| Shaft Diameter (mm) | 11 |
| Weight (lbs) | 10.89 |
| Single or Three Phase | Single |
Interested in large quantity discount?
Product Information
Anaheim Automation's single phase AC motors come in a variety of starting torques, rated torques and current. The ACW140-100-192 AC motor has a starting torque of 107.63 oz-in. They run at up to 1550 RPM with single phase 110 VAC, 60 Hz. The ACW140-100-192 offers torque ranges up to 122.21 oz-in. Other models are also available with gear ratios to provide even higher torques. Custom options for the Single Phase AC motor line include optimizing the maximum speed, torque, current, voltage, cabling, wiring, connectors, and shaft modifications.
Note: ACW Induction Motors are LTSOH (Limited to Stock on Hand).
- Single Phase AC Motor
- Torque up to 104.79 oz-in
- 100mm Motor Diameter
- 120 Watts of Power
- Can be Customized for
- Cables and Connectors
- Winding Current
- Shaft Options
- CE Certified and RoHS Compliant
