GBPS-1801-NM-008

GBPS-1801-NM-008

GBPS-1801-NM-010

GBPS-1801-NM-010

GBPS-1801-NM-009

Unit Price:
As low as $0.00
Quantity Discount
Inventory:
Out of Stock
More Information
Gear Ratio (X:1) 9
Rated Output Torque (in-lbs) 7081
Max Output Torque (in-lbs) 12746
Backlash Maximum (arc-min) 1
Maximum Input Speed (RPM) 6000
Stages 1
Efficiency (%) 97
Torsional Rigidity (Nm/arcmin) 75
L2 Length (mm) 94
Weight (lbs) 60.00
Interested in large quantity discount?

Product Information

The GBPS-180x Series is an In-Line Planetary Helical Gearbox line that offers great prices without sacrificing precision and quality. The GBPS-180x Series is designed for motion control applications requiring moderate backlash and stiffness. Features include backlash as low as 1 arcminute, 22 gear ratios for rated torque up to 9294 in-lbs (148,704oz-in), (model dependent), a precision clamping system and lifetime lubrication. Please verify all dimensions when matching a gearbox to a specific motor, as critical dimensions will vary among series and manufacturers.

  • Backlash as Low as 1 arc-min
  • Gear Ratios from 3:1 to 100:1
  • Long Design Life, Over 20,000 hrs
  • Up to 97 Percent Efficiency
  • Low Noise Helical Gears
  • Max Input Speeds Up to 6,000 RPM
  • Operating Temperature of -10° to +90° C
  • Lifetime Lubrication

Spec Sheet (PDF)
