TBI-TR20 Rails

TBI-TR20 Rails | Anaheim Automation, Inc.

Information

TBI-TR20 Rails are matched for TBI-TRx20 Blocks, and are offered in standard or custom lengths, with a continuous rail length up to 4000mm. For rail lengths longer than the full continuous length specification, rails can be butt-jointed to achieve the desired length. Please contact us for more information.

  • Rail Width: 20mm
  • Use with: TBI-TRx20 Blocks
  • Custom Rail Lengths Available
  • Continuous Rail Lengths up to 4000mm
Item Rail Dimension (mm) Rail Weight (lbs) Lead Time 1pc Price (USD) Add to Cart
W1 H1 F d x D x h Rail Length
Sort by Name TBI-TR20N-4000L W1 20 H1 16.5 F 60 d x D x h 6 x 9.5 x 8.5 Rail Length 4000 Rail Weight (lbs) 20.11 Lead Time 101 in stock 1pc Price (USD) $257.00 Call Us Contact Us
Sort by Name TBI-TR20N-3900-30-30 W1 20 H1 16.5 F 60 d x D x h 6 x 9.5 x 8.5 Rail Length 3900 Rail Weight (lbs) 19.61 Lead Time Typ 1-3 Days 1pc Price (USD) $288.00 Call Us Contact Us
Sort by Name TBI-TR20N-3700-20-20 W1 20 H1 16.5 F 60 d x D x h 6 x 9.5 x 8.5 Rail Length 3700 Rail Weight (lbs) 18.6 Lead Time Typ 1-3 Days 1pc Price (USD) $272.00 Call Us Contact Us
Sort by Name TBI-TR20N-3500-10-10 W1 20 H1 16.5 F 60 d x D x h 6 x 9.5 x 8.5 Rail Length 3500 Rail Weight (lbs) 17.6 Lead Time Typ 1-3 Days 1pc Price (USD) $261.00 Call Us Contact Us
Sort by Name TBI-TR20N-3300-30-30 W1 20 H1 16.5 F 60 d x D x h 6 x 9.5 x 8.5 Rail Length 3300 Rail Weight (lbs) 16.59 Lead Time Typ 1-3 Days 1pc Price (USD) $249.00 Call Us Contact Us
Sort by Name TBI-TR20N-3100-20-20 W1 20 H1 16.5 F 60 d x D x h 6 x 9.5 x 8.5 Rail Length 3100 Rail Weight (lbs) 15.59 Lead Time Typ 1-3 Days 1pc Price (USD) $234.00 Call Us Contact Us
Sort by Name TBI-TR20N-2900-10-10 W1 20 H1 16.5 F 60 d x D x h 6 x 9.5 x 8.5 Rail Length 2900 Rail Weight (lbs) 14.58 Lead Time Typ 1-3 Days 1pc Price (USD) $222.00 Call Us Contact Us
Sort by Name TBI-TR20N-2700-30-30 W1 20 H1 16.5 F 60 d x D x h 6 x 9.5 x 8.5 Rail Length 2700 Rail Weight (lbs) 13.58 Lead Time Typ 1-3 Days 1pc Price (USD) $211.00 Call Us Contact Us
Sort by Name TBI-TR20N-2500-20-20 W1 20 H1 16.5 F 60 d x D x h 6 x 9.5 x 8.5 Rail Length 2500 Rail Weight (lbs) 12.57 Lead Time Typ 1-3 Days 1pc Price (USD) $195.00 Call Us Contact Us
Sort by Name TBI-TR20N-2300-10-10 W1 20 H1 16.5 F 60 d x D x h 6 x 9.5 x 8.5 Rail Length 2300 Rail Weight (lbs) 11.57 Lead Time Typ 1-3 Days 1pc Price (USD) $184.00 Call Us Contact Us
Sort by Name TBI-TR20N-2100-30-30 W1 20 H1 16.5 F 60 d x D x h 6 x 9.5 x 8.5 Rail Length 2100 Rail Weight (lbs) 10.56 Lead Time Typ 1-3 Days 1pc Price (USD) $172.00 Call Us Contact Us
Sort by Name TBI-TR20N-1900-20-20 W1 20 H1 16.5 F 60 d x D x h 6 x 9.5 x 8.5 Rail Length 1900 Rail Weight (lbs) 9.56 Lead Time Typ 1-3 Days 1pc Price (USD) $157.00 Call Us Contact Us
Sort by Name TBI-TR20N-1700-10-10 W1 20 H1 16.5 F 60 d x D x h 6 x 9.5 x 8.5 Rail Length 1700 Rail Weight (lbs) 8.55 Lead Time Typ 1-3 Days 1pc Price (USD) $146.00 Call Us Contact Us
Sort by Name TBI-TR20N-1500-30-30 W1 20 H1 16.5 F 60 d x D x h 6 x 9.5 x 8.5 Rail Length 1500 Rail Weight (lbs) 7.54 Lead Time Typ 1-3 Days 1pc Price (USD) $134.00
Sort by Name TBI-TR20N-1300-20-20 W1 20 H1 16.5 F 60 d x D x h 6 x 9.5 x 8.5 Rail Length 1300 Rail Weight (lbs) 6.54 Lead Time Typ 1-3 Days 1pc Price (USD) $119.00 Call Us Contact Us
Sort by Name TBI-TR20N-1100-10-10 W1 20 H1 16.5 F 60 d x D x h 6 x 9.5 x 8.5 Rail Length 1100 Rail Weight (lbs) 5.53 Lead Time Typ 1-3 Days 1pc Price (USD) $107.00 Call Us Contact Us
Sort by Name TBI-TR20N-0900-30-30 W1 20 H1 16.5 F 60 d x D x h 6 x 9.5 x 8.5 Rail Length 900 Rail Weight (lbs) 4.53 Lead Time Typ 1-3 Days 1pc Price (USD) $96.00
Sort by Name TBI-TR20N-0700-20-20 W1 20 H1 16.5 F 60 d x D x h 6 x 9.5 x 8.5 Rail Length 700 Rail Weight (lbs) 3.52 Lead Time Typ 1-3 Days 1pc Price (USD) $80.00 Call Us Contact Us
Sort by Name TBI-TR20N-0500-10-10 W1 20 H1 16.5 F 60 d x D x h 6 x 9.5 x 8.5 Rail Length 500 Rail Weight (lbs) 2.52 Lead Time Typ 1-3 Days 1pc Price (USD) $69.00 Call Us Contact Us
Sort by Name TBI-TR20N-0300-30-30 W1 20 H1 16.5 F 60 d x D x h 6 x 9.5 x 8.5 Rail Length 300 Rail Weight (lbs) 1.51 Lead Time Typ 1-3 Days 1pc Price (USD) $57.00 Call Us Contact Us
Sort by Name TBI-TR20N-0150-15-15 W1 20 H1 16.5 F 60 d x D x h 6 x 9.5 x 8.5 Rail Length 150 Rail Weight (lbs) 0.76 Lead Time Typ 1-3 Days 1pc Price (USD) $46.00 Call Us Contact Us
Loading...
*Rail lengths larger than 2400mm require additional shipping charges and are not available for purchase online. Please contact our sales department to place an order.
