TBI-TR45 Rails

TBI-TR45 Rails | Anaheim Automation, Inc.

Information

TBI-TR45 Rails are matched for TBI-TRx45 Blocks, and are offered in standard or custom lengths, with a continuous rail length up to 4000mm. For rail lengths longer than the full continuous length specification, rails can be butt-jointed to achieve the desired length. Please contact us for more information.

  • Rail Width: 45mm
  • Use with: TBI-TRx45 Blocks
  • Custom Rail Lengths Available
  • Continuous Rail Lengths up to 4000mm
Item Rail Dimension (mm) Rail Weight (lbs) Price (USD) Add to Cart
W1 H1 F d x D x h Rail Length
Sort by Name TBI-TR45N-4000L W1 45 H1 32 F 105 d x D x h 14 x 20 x 17 Rail Length 4000 Rail Weight (lbs) 91.72 N/A Call Us
Sort by Name TBI-TR45N-3900-60-60 W1 45 H1 32 F 105 d x D x h 14 x 20 x 17 Rail Length 3900 Rail Weight (lbs) 89.42 N/A Call Us
Sort by Name TBI-TR45N-3705-15-15 W1 45 H1 32 F 105 d x D x h 14 x 20 x 17 Rail Length 3705 Rail Weight (lbs) 84.96 N/A Call Us
Sort by Name TBI-TR45N-3500-17.5-17.5 W1 45 H1 32 F 105 d x D x h 14 x 20 x 17 Rail Length 3500 Rail Weight (lbs) 80.25 N/A Call Us
Sort by Name TBI-TR45N-3300-22.5-22.5 W1 45 H1 32 F 105 d x D x h 14 x 20 x 17 Rail Length 3300 Rail Weight (lbs) 75.67 N/A Call Us
Sort by Name TBI-TR45N-3100-27.5-27.5 W1 45 H1 32 F 105 d x D x h 14 x 20 x 17 Rail Length 3100 Rail Weight (lbs) 71.08 N/A Call Us
Sort by Name TBI-TR45N-2900-32.5-32.5 W1 45 H1 32 F 105 d x D x h 14 x 20 x 17 Rail Length 2900 Rail Weight (lbs) 66.5 N/A Call Us
Sort by Name TBI-TR45N-2700-37.5-37.5 W1 45 H1 32 F 105 d x D x h 14 x 20 x 17 Rail Length 2700 Rail Weight (lbs) 61.91 N/A Call Us
Sort by Name TBI-TR45N-2500-42.5-42.5 W1 45 H1 32 F 105 d x D x h 14 x 20 x 17 Rail Length 2500 Rail Weight (lbs) 57.33 N/A Call Us
Sort by Name TBI-TR45N-2300-47.5-47.5 W1 45 H1 32 F 105 d x D x h 14 x 20 x 17 Rail Length 2300 Rail Weight (lbs) 52.74 N/A Call Us
Sort by Name TBI-TR45N-2100-52.5-52.5 W1 45 H1 32 F 105 d x D x h 14 x 20 x 17 Rail Length 2100 Rail Weight (lbs) 48.15 N/A Call Us
Sort by Name TBI-TR45N-1900-57.5-57.5 W1 45 H1 32 F 105 d x D x h 14 x 20 x 17 Rail Length 1900 Rail Weight (lbs) 43.57 N/A Call Us
Sort by Name TBI-TR45N-1710-15-15 W1 45 H1 32 F 105 d x D x h 14 x 20 x 17 Rail Length 1710 Rail Weight (lbs) 39.21 N/A Call Us
Sort by Name TBI-TR45N-1500-15-15 W1 45 H1 32 F 105 d x D x h 14 x 20 x 17 Rail Length 1500 Rail Weight (lbs) 34.4 N/A Call Us
Sort by Name TBI-TR45N-1300-20-20 W1 45 H1 32 F 105 d x D x h 14 x 20 x 17 Rail Length 1300 Rail Weight (lbs) 29.81 N/A Call Us
Sort by Name TBI-TR45N-1100-25-25 W1 45 H1 32 F 105 d x D x h 14 x 20 x 17 Rail Length 1100 Rail Weight (lbs) 25.23 N/A Call Us
Sort by Name TBI-TR45N-0900-30-30 W1 45 H1 32 F 105 d x D x h 14 x 20 x 17 Rail Length 900 Rail Weight (lbs) 20.64 N/A Call Us
Sort by Name TBI-TR45N-0700-35-35 W1 45 H1 32 F 105 d x D x h 14 x 20 x 17 Rail Length 700 Rail Weight (lbs) 16.05 N/A Call Us
Sort by Name TBI-TR45N-0500-40-40 W1 45 H1 32 F 105 d x D x h 14 x 20 x 17 Rail Length 500 Rail Weight (lbs) 11.47 N/A Call Us
Sort by Name TBI-TR45N-0300-45-45 W1 45 H1 32 F 105 d x D x h 14 x 20 x 17 Rail Length 300 Rail Weight (lbs) 6.88 N/A Call Us
Loading...
*Rail lengths larger than 2400mm require additional shipping charges and are not available for purchase online. Please contact our sales department to place an order.
