TBI-TRx15 Blocks

TBI's high-quality linear guides deliver precision, durability, and affordability. TBI-TRx15 Blocks are matched for the 15mm size TBI-TR15 Rail series. Low friction resistance allows for high accuracy and speed, while several preload options are available for increased rigidity and performance. TBI-TRH15 (high-assembly) Blocks are ideal for dynamic loads up to 13.1 kN (2944 lbs) and static loads up to 25.2 kN (5665 lbs), while TBI-TRS15 (low-assembly) Blocks are suited for dynamic loads up to 11.8 kN (2652 lbs) and static loads up to 21.6 kN (4855 lbs). All standard blocks come with a bottom seal and double lip end seals, and are typically in stock in Anaheim, CA. Compatible TBI-TR15 Rails are sold separately.

***NOTE: TBI-TRH15FL-N-Z0 blocks are NFND (Not For New Designs).

• For Rail Width: 15mm
• Block Width: 34, 47 or 52mm
• Assembly Height: 24 or 28mm
• Dynamic Load: Up to 2944 lbs (13.1 kN)
• Static Load: Up to 5665 lbs (25.2 kN)
• Rail Lengths up to 4000mm
• Options: End Seal, Preload, Accuracy, and More
