1pc Price:
$96.00
Quantity Discount
  • Buy 10 for $94.02 each and save 2%
  • Buy 25 for $90.07 each and save 6%
  • Buy 50 for $87.14 each and save 9%
  • Buy 100 for $84.39 each and save 12%
Inventory:
2
More Information
Input Type VAC
Input Range 85-135VAC
Max Power (W) 35
Peak Current (A) 3
Interested in large quantity discount?

Product Information

The MBDC050-024031-120V driver is designed to drive DC brush motors at peak currents of up to 3.0A and 35W. The MBDC050-024031-120V is a compact, low profile package meant to be used where space is limited but performance is expected and eliminates the need for an external power supply. The MBDC050-024031-120V driver is designed to drive DC brush motors at peak currents of up to 3.0A and 36W. The driver has a motor bus voltage of 24V. An external potentiometer (10K) or external voltage (0.5-5VDC) can be used to control the speed. The direction of the motor can be preset by the direction control input. To disable energy from the motor, there is a Freewheel input that can enabled by allowing current through the input opto-diode.

  • Fixed Current Limit Set at 3.0 Amps with an output power up to 35W
  • 0.5V to 5V External Voltage Speed Control
  • 2-Quadrant Operation
  • Open-Loop Velocity Mode
  • 24VDC Motor Bus
  • Requires 85-135 VAC Input
  • Freewheel and Direction Inputs
  • Cycle by Cycle Short Circuit Protection
  • Compact Size (4.73in X 3.19in X 1.54in)
  • Screw Type Terminal Block

User Manual (PDF)

Spec Sheet (PDF)
