GBPS-040x-CS
GBPS-040x-CS | Anaheim Automation, Inc.
Information
_Series.png)
The GBPS-040x Series is an In-Line Planetary Helical Gearbox line that offers great prices without sacrificing precision and quality. The GBPS-040x Series is designed for motion control applications requiring moderate backlash and stiffness. Features include backlash as low as 9 arcminutes, 20 gear ratios for rated torque up to 97 in-lbs (1557 oz-in), (model dependent), a precision clamping system and lifetime lubrication. Please verify all dimensions when matching a gearbox to a specific motor, as critical dimensions will vary among series and manufacturers.
See our GBPS Gearbox Installation Guide
- Compatible with NEMA Size 17
- Backlash as Low as 9 arc-min
- Gear Ratios from 3:1 to 567:1
- Long Design Life, Over 20,000 hrs
- Up to 95 Percent Efficiency
- Max Input Speeds up to 6,000 RPM
- Rated Output Torque from 71 to 97 in-lb
| Item | Gear Ratio (X:1) | Rated Output Torque (in-lbs) | Max Output Torque (in-lbs) | Backlash Maximum (arc-min) | Maximum Input Speed (RPM) | Stages | Efficiency (%) | Torsional Rigidity (Nm/arcmin) | Weight (lbs) | 1pc Price (USD) | Add to Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| GBPS-0403-CS-567 | 567 | 89 | 134 | 12 | 6000 | 3 | 85 | 1.2 | 1.69 | $454.00 - $471.00 | Call Us Contact Us |
| GBPS-0403-CS-315 | 315 | 97 | 146 | 12 | 6000 | 3 | 85 | 1.2 | 1.69 | $454.00 - $471.00 | Call Us Contact Us |
| GBPS-0403-CS-225 | 225 | 97 | 146 | 12 | 6000 | 3 | 85 | 1.2 | 1.69 | $454.00 - $471.00 | Call Us Contact Us |
| GBPS-0403-CS-125 | 125 | 97 | 146 | 12 | 6000 | 3 | 85 | 1.2 | 1.69 | $454.00 - $471.00 | Call Us Contact Us |
| GBPS-0402-CS-100 | 100 | 71 | 107 | 8 | 6000 | 2 | 90 | 1.2 | 1.27 | $350.00 - $368.00 | Call Us Contact Us |
| GBPS-0402-CS-081 | 81 | 71 | 107 | 8 | 6000 | 2 | 90 | 1.2 | 1.27 | $350.00 - $368.00 | Call Us Contact Us |
| GBPS-0402-CS-063 | 63 | 89 | 134 | 8 | 6000 | 2 | 90 | 1.2 | 1.27 | $350.00 - $368.00 | Call Us Contact Us |
| GBPS-0402-CS-049 | 49 | 97 | 146 | 8 | 6000 | 2 | 90 | 1.2 | 1.27 | $350.00 - $368.00 | Call Us Contact Us |
| GBPS-0402-CS-045 | 45 | 97 | 146 | 8 | 6000 | 2 | 90 | 1.2 | 1.27 | $350.00 - $368.00 | Call Us Contact Us |
| GBPS-0402-CS-035 | 35 | 97 | 146 | 8 | 6000 | 2 | 90 | 1.2 | 1.27 | $350.00 - $368.00 | Call Us Contact Us |
| GBPS-0402-CS-025 | 25 | 97 | 146 | 8 | 6000 | 2 | 90 | 1.2 | 1.27 | $350.00 - $368.00 | Call Us Contact Us |
| GBPS-0402-CS-020 | 20 | 97 | 146 | 8 | 6000 | 2 | 95 | 1.2 | 1.30 | $350.00 - $368.00 | Call Us Contact Us |
| GBPS-0402-CS-015 | 15 | 97 | 146 | 8 | 6000 | 2 | 95 | 1.2 | 1.30 | $350.00 - $368.00 | Call Us Contact Us |
| GBPS-0401-CS-010 | 10 | 71 | 107 | 6 | 6000 | 1 | 95 | 1.2 | 0.93 | $262.00 - $279.00 | |
| GBPS-0401-CS-009 | 9 | 71 | 107 | 6 | 6000 | 1 | 95 | 1.2 | 0.93 | $262.00 - $279.00 | Call Us Contact Us |
| GBPS-0401-CS-007 | 7 | 89 | 134 | 6 | 6000 | 1 | 95 | 1.2 | 0.93 | $262.00 - $279.00 | Call Us Contact Us |
| GBPS-0401-CS-005 | 5 | 97 | 146 | 6 | 6000 | 1 | 95 | 1.2 | 0.93 | $262.00 - $279.00 | |
| GBPS-0401-CS-004 | 4 | 89 | 134 | 6 | 6000 | 1 | 95 | 1.2 | 0.93 | $262.00 - $279.00 | Call Us Contact Us |
| GBPS-0401-CS-003 | 3 | 80 | 120 | 6 | 6000 | 1 | 95 | 1.2 | 0.93 | $262.00 - $279.00 | Call Us Contact Us |
Additional Information
Motor interface AA171-197 is compatible with Anaheim Stepper Motor series 14Y, 15Y, 17Y, 17Y9, and 17L, and with Anaheim Brushless Motor series BLY17xD, dual shaft motors. Choose a gearbox item from the product table above, and then select the appropriate motor interface ("suffix") on the individual product page to create a complete gearbox part number.
For custom input dimensions, or non-Anaheim Automation motors, fill out our Gearbox Mounting Form and submit it to our Sales Engineers at sales@anaheimautomation.com
Motor interface AA172-197 is compatible with Anaheim Brushless Motor series BLY17xS, single shaft motors. Choose a gearbox item from the product table above, and then select the appropriate motor interface ("suffix") on the individual product page to create a complete gearbox part number.
For custom input dimensions, or non-Anaheim Automation motors, fill out our Gearbox Mounting Form and submit it to our Sales Engineers at sales@anaheimautomation.com
Motor interface SMH40-315 is compatible with Anaheim Servo Motor series KNC-SRV-SMC40S and KNC-SRV-SMH40S. Choose a gearbox item from the product table above, and then select the appropriate motor interface ("suffix") on the individual product page to create a complete gearbox part number.
For custom input dimensions, or non-Anaheim Automation motors, fill out our Gearbox Mounting Form and submit it to our Sales Engineers at sales@anaheimautomation.com
